Monday, January 6, 2014

First Draft of SCA Kingdoms of the Eastern US & Canada Interactive Map

Woohoo! The first draft of SCA Kingdoms of the Eastern US and Canada Interactive Map is done! (See the link to the right.)  Conceptually, this hasn't been the most difficult project to work on, but in practice, well, that's a story in itself.  Let's just say it was much more challenging and tedious than expected.  Anyway, the data have been uploaded, maps made, and results shared!  Huzzah! Now for the next steps.

So I worked on the project on and off over the past few months, but decided to finish it over the holidays, sans SCA events and work.  The last bit was to consolidate or dissolve ZIP/FSA (postal) codes (areas) to the local groups and add website and Facebook URLs.  It also took a bit of work to add in the coastal buffers (to minimize the complex geometry and maximize website performance).  It's at this point, I was feeling done with it.  "But wait, there's more!"

A few things needed to happen in order to share the mapping results.  First, the data needed to be uploaded to the ArcGIS Online website.  Without getting too detailed, there is a very specific method for uploading the data in a way that maps can be made.  From here, each map layer is configured for visibility, symbology, and pop-up information.  It's pretty quick once you've worked out the details of the process.  I also learned that these configurations can be saved as layers and reused in other online maps.  The process was repeated for each kingdom then compiled using the layer files in the SCA Kingdoms of the Eastern US and Canada Interactive Map.  Once all of this information was made public, I embedded the HTML code into the blog page, wrote an FAQ, and started to share the good word.  I finally have time to write about it.  =)

As I've shared the information with the other team members, I'm coming to realize what's next. At some point we'll need to consolidate our map information as well as prepare for the initial round of updates.  Hopefully edge-matching Kingdoms will go pretty well, but there will probably be some editing.  The updates should be interesting.  As far as I know, branch seneschals are responsible for maintaining the complete list of postal codes for their branch.  The problem is postal codes, and seneschals, change over time.  As new neighborhoods get built, postal routes change.  Often new ones are added and occasionally old ones are removed due to shrinking populations in rural areas.  Not to mention, changes in post office box locations and newly opened/closed businesses that get their own ZIP code (i.e. large corporations).  It's likely seneschals don't check or have the means to look for postal code changes in their areas.  While working on the project I also noted that many groups define their boarders based on counties, not postal codes.  This is problematic because postal codes can have more area outside their target county than in it.  In other cases, I found unclaimed postal codes.  Sometimes it's obvious which group a postal code belongs to, but not always.  I labelled them "Crown Lands" until branches and Kingdoms decide where to allocate them.  Needless to say, there will be corrections.  And as a by-product of this project, each Kingdom will get a complete list of regions, primary branches, subsidiary branches, and URLs for websites and Facebook pages.

This is certainly a big project. To date, I think I've put in 50 to 60 hours.  It hasn't been terribly difficult, just tedious organizing, sorting, standardizing, and configuring it all.  Database and GIS people are crazy.  ;-)

Tuesday, December 10, 2013

Posters, Events, and Progress

OK, OK. I haven't posted anything in a month, but I have been working on this project! Really! I've made posters and displayed them at events to get the word out and cut regions into the Kingdom polygons. With the deadline of December 31, 2013 looming, I'm focusing on mapping kingdom branches.

There was an East Kingdom Service University on November 23, 2013 in Concord, NH (http://ekserviceuniversity.wordpress.com/).  There were some great classes and I wanted to lead a round-table discussion on SCA recruitment (or "talent scouting") with Sir Kyppyn Kirkcaldy.  As far as I know, there haven't been too many Service Universities over the years, so I figured this would be a good venue for some posters.

The first poster was one I made for The Fort Knox Medieval Tournament in September, which is an SCA public demonstration hosted by the Barony of Endewearde at Fort Knox in Bucksport, ME.  Over the years, I've come to realize that people from all over Maine visit the Fort and see our demo.  Some want to know if there is an SCA group where they live. What a great opportunity for a map!  I collected contact information from each of the groups (including groups just getting started) in Maine and made a QR code for their website or social media page.  I need to work on a few things, but it turned out pretty well.  My goal is to print more of these and share them with the other groups so that we can all benefit from them at other SCA demos.  I'll be elated if anyone pulls out a smart phone, scans the QR code, and contacts the local representative.  Fingers-crossed!


The next poster was for the SCA Known World Mapping Project.  Because the East Kingdom is mostly mapped, I used it as a proof of concept.  It show the extent of the East Kingdom, the regions and Principality of Tir Mara, and the local branches.  It introduces the project team, goals, progress, the smart phone/tablet app, and this blog.  I kept the "WGS 1984 Web Mercator Auxiliary Sphere" projection in the three main maps, which I should probably change.  It makes Canada look HUGE and the rest of the Kingdom tiny.  Labeling the state-side branches was a bit of a challenge and later discovered that a couple didn't get labeled.  Oops.  All-in-all, it's a good start.  I even saw a slight bump in blog views!

The maps are taped down to foam-core, poster board which I left in the trunk of my car after the Service University.  I brought them to our fighting and fencing practice the following Sunday, where my daughter is a youth fencer.  Mistress Mercedes, EK Seneschal & New Groups person, was there and had a question about the location of a group.  I brought the Known World Mapping Project map of the East Kingdom in and she quickly discovered that it would make sense for a certain incipient group to be part of the Central Region instead of the Southern Region.  Maps can certainly help make informed decisions!

Both maps have since made trips to the Herne the Hunter event in the Barony of Ruantallan (Halifax, NS) and the Barony of Endewearde holiday revel.  The feedback has been positive and suggestions for improvement or corrections have been made.  I certainly appreciate the interest and cooperation.

Cutting the Kingdom regions into a copy of the Kingdom polygons was pretty easy.  From what I can tell, Trimaris doesn't use regions, Meridies and goes by state boarders, Atlantia, AEthelmearc, and the East use state/country boundaries and branch divisions.  There were a few hiccups along the way for unaccounted ZIP/ZCTAs codes, but they are mostly figured out.  I hope to post that map data shortly.

The big hurdle is corroborating ZIP code lists by the Kingdoms to the ZCTAs.  So far I have found orphaned ZCTAs and a few claimed by more than one group.   There are also questions based on published maps compared to what the Kingdom list/mapped ZCTAs are showing.  I suspect one is more current than the other.  I think there is going to be a beta period to work out the errors.  Once this is done, I'm sure the Kingdoms will appreciated updated ZIP code lists for their local branches.  It's easy to see that this project is going to take a bit of work to keep it updated.  (Let's worry about that later...).

That's it for now.  The work continues!  =)

Friday, November 8, 2013

Progress Report for Friday, 11/8/13

Over the last week or so, I've had a chance to consider the data structure, start looking at linking tabular data to spatial data, think about deadlines, and add a ZIP code basemap to my EK demo map. Here's where we're at to date:

There are 5 people working on this project, so naturally, we'll have 5 methods for getting to our goal. It was agreed we wanted an interactive map that would make it easy to find which SCA branch a particular ZIP/FSA code fell into. One way would be to simply assign a branch to a ZIP/FSA code and show it on a map. That's fine in a desktop software application, but we also want to serve it up in a map on the internet. The limitations here are file size, the number of features (records in the table), and complexity of the geometry. Basically, we can't upload all of the ZIP/FSA codes to the website and expect the back-end servers to render that much data. We have to dumb it down a bit. This means dissolving the ZIP/FSA codes to the branches. Then, if we want to zoom out to see Kingdoms, zoom halfway to see regions, or zoom in further past Baronies & Shires to see cantons, ridings, colleges, ports, or stongholds, that has to be in the dataset as well. We can dissolve the ZIP/FSA polygons to each level. That means there will be a Kingdom level, regional level (Principalities or groups of branches for those kingdoms that have them), a Barony/Province/Shire level, and a canton/riding/college/port/stonghold level. Breaking the ZIP/FSA codes down this way means that at a minimum, the table must have these four columns. The added benefit is that we can show which local levels belong to which parent levels. OK, so I've spent a lot of time thinking about this, but it seems logical to me. (Another complication will be islands and coastlines, but I'll get to that later.)

So now that I have spreadsheets of branches by ZIP/FSA codes, I'll need to link them to the corresponding ZIP/FSA polygons. Linking the data based on ZIP/FSA codes is pretty easy, it's the clean-up that stinks. There will undoubtedly be orphaned ZIP codes because the polygons are ZIP Code Tabulation Areas (ZCTAs). ZCTAs are ZIP codes used by the U.S. Census Bureau. You can read more about ZCTAs at this website: http://www.unitedstateszipcodes.org/.  Anyway, there are more ZIP Codes than ZCTAs.  Also, ZIP Codes get added and deleted all the time, so we're bound to find some that local Seneschal's missed or are legitimately "Crown Lands" unclaimed by local branches.  This clean-up will probably be the most time consuming part.

With so much work to do, knowing timelines and deadlines will help.  Most of the SCA Known World Mapping Team will be discussing this Saturday evening (11/9/13).  One deadline mentioned so far was by the end of the year.  That's about seven weeks from today.  Seems reasonable (I hope).

Finally, there has been this idea that we would want to see the ZIP (ZCTAs) code boundaries.  Luckily ESRI has done this work for us!  I'm not sure how they did it, but the layer can be added to the map and rendered the way we want to see it.  I've added another page to the blog called, "SCA EK Branches with ZIP Code Basemap".  If you zoom down to the local branch level, you'll see the ZIP code polygons.  Pretty neat!  I'd still prefer to enter a ZIP code and search/zoom to it though.

This project is still a work in progress, but a labor of love.  I'm excited for people to use it.  =)

Tuesday, October 29, 2013

Embedded Maps

Out of the blue this morning, it occurred to me that it's possible to embed ArcGIS Online maps in websites and Blogger allows you to create additional pages and view the HTML code in the editor.  Putting the two together, you'll notice a "Pages" section to the left and a link to "SCA East Kingdom Branches Demo Page".  Go ahead and click it.  I'll wait....

Cool, eh?  I don't know why I didn't think of it sooner.  I imaging Kingdom Web Ministers will want to do this with their sites too.

Thursday, October 24, 2013

Working Smarter, Not Harder


If one had a field of barley to harvest or bushels of grapes to crush, it would be good to have friends.  Medieval crowd sourcing?  Well, I'm glad to have friends willing to comb the inter-webs for website info.  You can read more about it here:

Tuesday, October 22, 2013

Sorting and Classifying Kingdom ZIP Codes

In order to map SCA branches by kingdom, the ZIP and FSA (Forward Sortation Area - Canada) codes have to be classified by Kingdom, region, primary and subsidiary branches.  These classifications will be scale dependent in the final map.  To develop the map, each Kingdom provided a list of ZIP/FSA codes by branch for this project.  Quite a bit of reformatting and editing was required to get the data "database ready".

The final product of this project is an interactive map that revels SCA groups at different scales (or zoom extents).  So if someone zooms out of the map far enough to see North America we should see Kingdom boarders.  Zooming to the region and state level should revel regions within a Kingdom.  Zooming to the State and county level should show Baronies and Shires.  Finally, zooming to the Barony or Province level should show the Barony proper and any cantons/ridings or colleges associated with the Barony or Province.  Keeps and Ports will figure into this as well; though the associated ZIP codes may appear as points rather than areas.

The map design means that each ZIP/FSA code must have a Kingdom, region, primary and, if required, subsidiary group names; where the type of group is part of the name for primary and subsidiary branches.  It's a database thing.  This ZIP/FSA code list will be used to link to a spatial database of ZIP codes.   We are effectively adding additional information to a map point or polygon ZIP/FSA code.

As you can imagine, each Kingdom has a different method of formatting these lists in a spreadsheet.  Most provided only the branch name and list of associated ZIP/FSA codes, while others included the region, type of branch and associations with the ZIP/FSA codes.  For example, in the former case, only the group name and list of ZIP codes was given and in the later case, the type of group (Barony, Canton, College, Shire, etc) and name plus which Barony the Canton or College belongs to as well as the ZIP/FSA codes were provided.  In order to get the information provided into a standard format for the spatial database it was necessary to "fill-in-the-blanks".  It's fortunate that SCA membership affords us the ability to download newsletters from other Kingdoms than our own.  I downloaded the AEstel, Acorn, PikeStaff, Popular Chivalry, and Talewinds newsletters to classify the ZIP/FSA codes.  Each newsletter has a page with group contact information.  Simply listing the names made it possible to determine the region, type of group, affiliation to a parent group, and even the correct spelling of a group name.

Once the ZIP/FSA code list is completely classified, it is possible to summarize the data.  Microsoft Excel's data filtering and Pivot Table tools makes this very easy.  A count of regions, groups within a region or Kingdom, or a count of groups by type is done in a matter of minutes.  A count of ZIP/FSA codes is helpful for the kind of data preparation this project calls for.  Here is a draft summary of the Kingdom of AEthelmearc:

Kingdom of Aethelmearc
REGION PRIMARY SUBSIDIARY Count of ZIPCODE
1 1,064
Barony of Blackstone Mountain 619
Shire of Ballachlagan 23
Shire of Misty Highlands 267
Shire of Port Oasis 84
Shire of Sylvan Glen 71
2 605
Barony Marche of the Debatable Lands 178
Canton of Steltonwald 18
College of Cour d'Or 3
(blank) 157
Shire of Gryffyns Keep 102
Shire of Hunter's Home 53
Canton of Steltonwald 3
(blank) 50
Shire of Kings Crossing 83
Shire of Riversedge 21
Shire of Stormsport 51
Shire of Sunderoak 117
2.3 6
DL--SSB 6
GK--WM 6
3 735
Barony of Endless Hills 230
Barony of Hornwood 69
Barony of St. Swithin's Bog 148
Crown Lands 41
Shire of Abhainn Ciach Ghlais 147
Shire of Nithgaard 100
4 461
Barony of Rhydderich Hael 153
Canton of Beau Fleuve 25
(blank) 128
Barony of Thescorre 166
Shire of Blackwater 29
Shire of Hartstone 42
Shire of Heronter 71
5 490
Barony of Delftwood 114
Dominion of Myrkfaelinn 83
Shire of Angel's Keep 7
Shire of Coppertree 118
Shire of Courtlandtslot 15
Shire of Sterlynge Vayle 88
Shire of Wynterset 65
Grand Total 3,361

In this table, "(blank)" is the barony proper, not the canton or college count of ZIP codes.  There is also the question of the Canton of Steltonwald having ZIP codes in two parent groups and the "2.3" region.  However, we can see that there are 5 regions, 29 baronies, shires, and a "Dominion", as well as 3 cantons and 1 college.  Altogether, there will be 3,361 tabular ZIP codes that need to match polygon or point ZIP code features.

Here's what I have so far for the other Kingdoms on my list:

Kingdom of the East
Region PRIMARY SUBSIDIARY Count of ZIP Code
Principality of Tir Mara 633
Barony of L'ile du Dragon Dormant 215
Barony of Ruantallan 82
Canton of Distant Shore 1
Canton of Seashire 26
Canton of Ynys Y Gwaed 7
Ruantallan Proper 48
Crown Lands 1
La baronnie du Havre des Glaces 113
La Selve d'Aure 25
Shire of Ar n-Eilean 34
Shire of Bois Ardent 23
Shire of Le Dragonet 30
Shire of Lyndhaven 110
Northern 1,256
Barony of Stonemarche 276
Stonemarche Proper 276
Crown Lands 94
Province of Malagentia 158
Malagentia Proper 154
Incipient Riding of Giggleswick 4
Shire of Coldwood 46
Shire of Glenn Linn 63
Shire of Mountain Freehold 80
Shire of Northern Outpost 73
Shire of Panther Vale 127
Shire of Smithwick 53
Barony of Endewearde 244
Incipient Canton of Wyndriche 30
Endewearde Proper 214
Incipient Shire of Hadchester 42
Central 1,673
Barony Beyond the Mountain 248
Canton of Bowman's Rest 84
Canton of Dragon's Aerie 28
Canton of Fennbrycg 84
Canton of Ravenhill 52
Barony of Bergental 160
Bergental Proper 160
Barony of Carolingia 249
Canton of Aschehyrst 20
Canton of The Towers 93
Carolingia Proper 136
Barony of Concordia of the Snows 171
Concordia Proper 171
Barony of Dragonship Haven 168
Canton of Seatygers Rhyn 45
Dragonship Haven Proper 75
Dragonship Proper 48
Barony of Smoking Rocks 170
Smoking Rocks Proper 170
Barony of the Bridge 91
Bridge Proper 91
Crown Lands 168
Shire of Anglespur 29
Shire of Coill Tuar 17
Shire of Frosted Hills 37
Shire of Nordenhalle 48
Shire of Quintavia 117
Southern 2,362
Barony of An Dubhaigeainn 115
An Dubhaigeainn Proper 90
Canton of Hawk's Reach 25
Barony of Bhakail 170
Balliwick of Ivyeinrust 10
Bhakail Proper 141
Canton of Black Icorndall 19
Barony of Carillion 164
Canton of Forestgate 46
Canton of the Keep by the Endless Sea 23
Carillion Proper 95
Barony of Iron Bog 77
Iron Bog Proper 77
Barony of Settmour Swamp 250
Canton of Gryphonwald 35
Canton of Marwick 35
Settmour Proper 180
Crown Lands 18
Crown Province of Ostgardr 547
Canton of Brokenbridge 52
Canton of Lions End 102
Canton of Northpass 100
Canton of Whyt Whey 147
Ostgardr Proper 146
Shire of Barren Sands 88
Shire of Blak Rose 87
Shire of Buckland Cross 64
Shire of Caer Adamant 98
Shire of Coill Tuar 1
Shire of Eisental 197
Shire of Hartshorn-dale 100
Shire of Montevale 78
Shire of Owlsherst 56
Shire of Rusted Woodlands 162
Shire of Silver Rylle 90
Grand Total 5,924
Kingdom of Atlantia
REGION PRIMARY SUBSIDIARY Count of ZipCode
Maryland 889
Barony of Bright Hills 152
Barony of Dun Carraig 66
Barony of Highland Foorde 85
Barony of Lochmere 70
Barony of Storvik 345
Shire of Roxbury Mill 56
Shire of Spiaggia Levantina 115
North Carolina 1,011
Barony of Hawkwood 206
Barony of Raven's Cove 13
Barony of Sacred Stone 436
Canton of Aire Faucon 38
Canton of Baelfire Dunn 76
Canton of Charlesbury Crossing 121
Canton of Crois Brigte 93
Canton of Middlegate 82
Canton of Salesberie Glen 15
(blank) 11
Barony of Windmasters' Hill 275
Canton of Attillium 54
Canton of Buckston-on-Eno 25
Canton of Elvegast 54
Canton of Kappellenberg 8
Canton of Nimenefeld 12
(blank) 122
Shire of Cathanar 28
Shire of Seareach 53
South Carolina 632
Barony of Hidden Mountain 278
Canton of Misty Marsh by the Sea 86
Canton of Tear-Sea's Shore 132
(blank) 60
Barony of Nottinghill Coill 354
Canton of Brockore Abbey 52
Canton of Cyddlain Downs 127
Canton of Falcon Cree 112
Canton of Ritterwald 6
(blank) 57
Virginia 810
Barony of Black Diamond 135
Barony of Caer Mear 147
Canton of Caer Gelynniog 11
Canton of Rivers Point 14
(blank) 122
Barony of Marinus 70
Barony of Ponte Alto 123
Barony of Stierbach 158
Canton of Abhainn Iarthair 20
Canton of Sudentorre 35
(blank) 103
Barony of Tir-y-Don 45
College of Rencester 5
(blank) 40
Shire of Berley Cort 26
Shire of Isenfir 106
(blank) 657
Crown Lands 657
(blank) 657
Grand Total 3,999


Kingdom of Meridies
REGION PRIMARY SECONDARY Count of ZIPCODE
Alabama 399
Barony of Iron Mountain 96
Barony of the Osprey 96
Incipient Shire of Ironstone Springs 3
Shire Des Forges 18
Shire of An Dun Theine 60
Shire of Glynn Rhe 50
Shire of Okebourne Keep 23
Shire of the Eagle 6
Shire of Thorngill 47
Florida 69
Barony of the Osprey 16
Incipient Shire of Ironstone Springs 4
Shire of Arenal 33
Shire of Phoenix Glade 16
Georgia 638
Barony of Bryn Madoc 33
Barony of South Downs 184
Incipient Shire of Depedale 11
Incipient Stronghold of Stags Gate 61
Shire of Beau Fort 32
Shire of Drakenmere 11
Shire of Flintmarsh 12
Shire of Forth Castle 46
Shire of Marion Glen 25
Shire of Owl's Nest 60
Shire of Sol Haven 28
Shire of Talmere 38
Shire of Tir Briste 50
Stronghold of Ravenwood 47
Kentucky 93
Shire of Loch an Fhraioch 18
Shire of Redwulfden 75
Tennessee 444
Barony of Thor's Mountain 125
Canton of Hochwald 7
(blank) 118
Shire of Crimson River 10
Shire of Easaraigh 53
Shire of Glaedenfeld 86
Shire of Loch Cairn 31
Shire of Nant y Derwyddon 65
Shire of Rising Stone 33
Shire of Vulpine Reach 41
(blank) 119
Crown Lands 119
Grand Total 1,762


Kingdom of Trimaris
PRIMARY SUBSIDIARY  Count of ZIPCODE
Barony of An Crosaire 108
Canton of Amurgorod 48
Canton of Mathom Trove 23
(blank) 37
Barony of Darkwater 157
Canton of Loch Gryphon 33
Canton of Peregrine Springs 26
Canton of Swampkeype 15
(blank) 83
Barony of Marcaster 151
Canton of Steadboro 77
(blank) 74
Barony of Oldenfeld 34
Barony of Wyvernwoode 93
Crown Lands 133
Shire of Bentonshire 34
Shire of Castlemere 59
Shire of Fiadh Ogain 35
Shire of Sangre del Sol 104
Shire of Sea March 60
Shire of Southkeep 136
Shire of Stag Ridge 11
Shire of Starhaven 47
Shire of Suderholt 8
Shire of the Ruins 60
Shire of Tri Os 31
Shire of Trystelle Tre 49
Shire of Vaca del Mar 54
Stronghold of Nan Crioch Tuatha 6
Grand Total 1,370
